Description
| AC CAPACITY | 1.5 Ton |
|---|---|
| Outdoor Unit Model | AOGA-18FBTBH |
| POWER SOURCE (V/Ø/HZ) | 220-240/1/50 Hz |
| RUNNING CURRENT (A) | 6.70-6.30 |
| MOISTURE REMOVAL (LITER/H) | 1.6 |
| SOUND PRESSURE (INDOOR) | 35 dB(A) |
| SOUND PRESSURE (OUTDOOR) | 54-54 dB(A) |
| NET DIMENSION – INDOOR (H X W X D) (MM) | 246×840×840 |
| NET DIMENSION – OUTDOOR (H X W X D) (MM) | 650×830×320 |
| NET WEIGHT – INDOOR (KG) | 24.0(52.9)/6(13) |
| NET WEIGHT – OUTDOOR (KG) | 50.0(110.2) |
| PIPING CONNECTIONS (SMALL / LARGE) (MM) | 6.35/15.88 |
| DRAIN PIPE DIAMETER (I.D./O.D.) (MM) | 25.0/32.0 |
| OPERATION RANGE (°CDB) | 21-52 |
| REFRIGERANT | R410A |
| COMPRESSOR | Rotary |
| CONDENSER MATERIAL | Copper |
| REMOTE CONTROL | Wired |
| INDOOR AIRFLOW RATE (M3/H) | 1,150 |
| OUTDOOR AIRFLOW RATE (M3/H) | 3060-3200 |
